Effluent Pumps SepticEffluent Pumps (Septic)Effluent Pumps Septic
An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. Effluent Pumps are specifically engineered to handle the tough, demanding tasks of effluent waste transfer with high efficiency and long-term dependability.
Pressure Dozing Pump Package
Includes:
    Goulds EP0511  1/2 Hp, 115 Volt Effluent Pump |    High Level Alarm |    On/Off Float |    All Fittings |    75 feet of 12-2 and 14-2 UF Cable
  • Additional Cable is available at additional cost
  • 230 Volt Pumps are available at an additional cost
  • Cable runs in excess of 150 ft require a 230 volt pump
PUMPS
EP0511AC 1/2 Hp 115v
EP0512F 1/2 Hp 230v

performance curve for model 3871 effluent pumps  Performance Curve series 3871 submersible effluent pumps     Click for larger image   |    pdf file icondownload PDF

WE0311M 1/3 Hp 115v
WE0312M 1/3 Hp 230v
WE0511H 1/2 Hp 115v
WE0511HH 1/2 Hp 115v
WE0512H 1/2 Hp 230v
WE0512HH 1/2Hp 230v
WE0712H 3/4 Hp 230v
WE1012H 1 Hp 230v (Control Panel Recommended)
WE1512H 1 1/2 Hp 230v (Requires Control Panel)
WE2012H 2 Hp 230v (Requires Control Panel)

performance curve for effluent pumps  Performance Curve series 3885 submersible effluent pumps     Click for larger image |    pdf file icondownload PDF

Upgrade vs. Box Price the Box Price is for just the pump in the shipping box. The Upgrade Price is added to the cost of the Standard Pump Package listed above in place of the standard EP0511AC effluent pump.

Alarm
Single Float On/Off (Super Jr)
Double Float

Complete Price List - prices in effect 03/01/2024
pdf file icon download PDF
